简介

In response to the cloud computing trend, Apacer first to offer the high-capacity, ultra-speed performance, outstanding IOPs and proven reliablity SSDs dedicated to servers and networking devices through an ongoing development and customization. The Apacer Serial ATA Flash Drive (SAFD) 25P-M allows server systems to achieve optimal complete performance; assisting servers accelerate data processing in today high-intensity oprating applications.

Apacer, in consideration of cost and capacity for customers, introduces the MLC (Multi-Level Cell) offerings with cost structure advantage, SAFD 25P-M. It offers 16GB, 32GB, 64GB, 256GB and 512GB capacities, with sequential read/write speeds reaching up to 260 and 220 MB/sec, respectively. To work normally in harsh operating environments, Apacer SAFD 25P-M employ the guaranteed wide-temp chip, which means it can run stably under industry-level extended-temperature (-40°C ~ 85°C) environments for the highest reliability and longest lifespan. And also, it boasts a built-in S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) technology and intelligent power failure recovery function to safeguard data and enhance product stability.

突出显示

Perfect replacement of 2.5 inch SATA HDDs

Global Wear-leveling and Block Management

Built-in ATA Secure Erase and S.M.A.R.T. Functions

Intelligent Power Failure Recovery

Trim Command Support

MLC Extended Temperature Support (Optional)

规格

型号 SAFD 25P-M

接口 SATA 2.0 (3Gb/s)

连接器 (7+15) pin male

外形(英寸) 2.5

NAND闪存类型 MLC

容量 16GB~512GB

持续读取能力(MB/秒) Up to 260

持续写入能力(MB/秒) Up to 220

ECC支持 Built-in hardware ECC, enabling up to 16/24 bit correction per 1024 bytes

标准工作温度 0 ~ + 70

扩展工作温度 ( °C ) -40 ~ + 85＊

(＊=Supports 32GB~256GB)

存储温度 -40 ~ + 100

冲击 1500G

振动 15G

湿度 5%~95%

工作电压 5.0 V ± 5%

低功耗 Active mode: 872 mA & Idle mode: 203 mA

MTBF (hours) >1,000,000

尺寸(mm) 100(L)x69.8(W)x9.3(H)
